Description
DIG 710A Battery Operated Controller (710A-000) pre-installed with a Hunter 2-inch PGV In-Line Valve
Powered by two AA alkaline batteries that last up to three years, the 710A series controllers offer installation flexibility and simple programming for easy operation and maintenance, including seven buttons with a large, easy-to-read LCD screen and icon-based programming with five start times per day in weekly or cyclical mode. Additional features include monthly budget, rain delay of up to 99 days with automatic restart, 20 preset smart programs utilizing historical ET, and monthly and daily programming restriction options to comply with city and municipal codes.
Distinguished among the 710A features are twenty Simple Smart programs based on monthly historical Evapotranspiration (ET) for spray heads and drip irrigation, with an editing feature that can be used as part of the controller programming. Combining one of the historical Evapotranspiration preset programs and a rain sensor can help seasonally adjust or prevent unnecessary watering. Pre-installed with a 1.5” professional grade Hunter PGV in-line/angle valve with flow control.
710A Controller Features
- Powered by two AA alkaline batteries with a 60 second safe period when replacing batteries that prevents the settings from being lost
- Watering flexibility with a selection of watering frequencies including weekly, odd, even, and cyclical with five start times per day
- Seven buttons with integrated high resolution screen
- Three year warranty
- Custom programming schedules with a weekly calendar, odd days, even days, intervals from one to thirty (1-30) days or 1 to 12 hours utilizing yearly calendar with leap year
- Five start times per day in normal programming and one start time per day in intervals of 1 to 12 hours
- Durations up to 5 hours and 59 minutes in one-minute increments
- 20 preset historical ET programs available for 10 climate zones, with 10 for drip irrigation and 10 for spray heads, to use with any irrigation setup and including the option to review the new calculated duration
- Monthly seasonal adjustment through the seasons with option to reduce the program duration setting to 0 or to increase it up to 200% in 5% increments without modifying the controller’s program duration; also can be used to fine-tune the preset ET program for each month
- Manual On/Off button with semi-automatic feature utilizing the program runtime and shows the time left to run with quick override
- Daily and monthly programming restriction feature allows controller to bypass irrigation schedules. Can be used to comply with city and municipal watering restrictions.
PGV Valve Features
- Connection Size: 2” FPT (Female Pipe Thread)
- Flow rate: 20 to 150 GPM
- Recommended pressure range: 20 to 150 PSI
- Temperature rating: 150° F
- All Hunter valves are 100% water tested to ensure reliable operation once installed
- Captive bonnet bolts provide hassle-free valve maintenance and eliminate the possibility of lost parts during disassembly
- Each valve available with globe or angle configuration for convenient placement
- Flow control maximizes efficiency and prolongs the life of the system
- External and internal manual bleed allows quick and easy at the valve activation
- A double-beaded diaphragm seal design for superior leak-free performance
- Triple-tool bonnet screws are compatible with standard or Phillips screwdrivers as well as a nut driver
- Hunter valve pre-installed with DIG 30-922 adapter for use with DIG battery operated controllers.
Downloads & Spec Sheets
- 710A Owner’s Manual
- 710A Spec Sheet
- PGV Spec Sheet
