Brilliance 75W Transformer
DESCRIPTION:
The Brilliance Transformer features a high-quality, stainless steel case and includes multi taps to accommodate voltage drop. These Transformers are sure to support any size of project.
Create up to four zones on a single transformer with up to 200 Watts per sector with the award-winning Sector Selector (sold separately).
Transformer Specs
- Wattage: 75
- Finish: Stainless Steel
- Photocell/Timer: Photocell included/Timer sold separately – Smart Socket 3.0
- Secondary Circuit Breaker: Red
- Multi Tap: 12V, 15V
- Dimensions (in): 3.75 x 5.75 x 4.25
- Dimmable: On Primary Side
- Warranty: Lifetime
FEATURES:
- UL 1838 Certified
- Secondary circuit breaker
- Two knockout sizes for conduit
- Removable bottom & 4ft Grounded plug
- Canted terminal block for easy access
TECHNICAL REQUIREMENTS
Design and plan lighting systems with volt amps in mind. Use the Brilliance Volt Amps chart to estimate the total draw on the system and choose the appropriate size of transformer accordingly.
INSTALLATION AND OPERATIONAL REQUIREMENTS:
See the Brilliance Transformer Guide for full installation and operational requirements and instructions.
Downloads
- Transformer Cut Sheet
- Transformer Flyer
- Transformer Guide
- Volt Amps
