Description
The I-25 gets the job done with power, efficiency, and commercial-grade reliability. With a robust watering radius of 45′ to 70′, this rotor can be used in a variety of applications and environments.
A standard check valve is built in, and a wide selection of high performance nozzles are available. Efficient, tough, and built-to-last, Hunters I-25 rotors work hard day in and day out so you don’t have to.
This is a case pack of 12 x I25-04 Rotors.
Includes:
- (12) I25-04 4” Pop-up Rotors with Check Valve
- (5) Standard Nozzles are included per Rotor. (Includes #07, #10, #15, #20, #25)
- (2) Rotor Keys included. – Rotor key is part 172000.
- (1) Optional Nozzle Changer Clip – 123200
- (1) Instruction Sheet
Operating Specifications
- Radius: 45′ to 70′ (with Nozzles Included)
- Flow rate: 6.6 to 29.5 GPM
- Recommended pressure range: 40 to 100 PSI
- Operating pressure range: 40 to 100 PSI
- Precipitation rates: 0.4 in/hr approx.
- Nozzle trajectory: 25 degrees
Features
- Model: 4″
- Riser: Plastic
- Inlet Size: 1”
- Arc setting: 50 to 360 degrees
- Patented non-reversing 360 for part- and full-circle in one model, from 50 to 360 degrees
- Pre-Installed Drain Check Valve (UP TO 10 FT. OF ELEVATION). The drain check valve keeps lines from draining when the system is shut off. This saves water, reduces liability, and increases system life.
- QuickCheck™ arc mechanism for fast arc adjustment
- Color-coded nozzles make identification easy
- Nozzle choices: 12 ((5) Standard Nozzles included, others purchased separately)
- Nozzles Included: #07, #10, #15, #20, #25
- Nozzle range: #4 to #28
- Warranty period: 5 years
Specifications
- Overall height: 7⅞”
- Pop-up height: 4″
- Exposed diameter: 1¾”
- Inlet size: 1″
Downloads
- Nozzle Specifications
- I-25 Brochure
- Spec Sheet
- Commercial Rotor Support
