Description
The industrys most flexible irrigation controller solution that supports flow monitoring, LNK WiFi, and up to 22 stations using ESP Expansion Modules.
Upgrade the ESP-ME3 to a SMART controller with EPA WaterSense certification by adding the LNK WiFi module and a WR2 rain sensor. The LNK makes programming and monitoring easy through the enhanced Rain Bird app. For even greater water monitoring and protection from a broken irrigation system install a flow sensor.
Features
- 4 station base capability, expandable up to 22 stations using hot-swappable 3- or 6-station expansion modules (sold separately)
- Comes with power plug and outdoor cabinet for indoor or outdoor installation.
- Upgradeable for WiFi-based remote monitoring and control via iOS and Android mobile devices from anywhere in the world (with LNK2 WiFi Module sold separately)
- Internet-based weather information can be used to make daily adjustments to the irrigation schedule, saving up to 30% in water (with LNK2 WiFi Module sold separately)
- Back-lit LCD display for improved visibility in low-light and direct sun conditions
- Large LCD display with easy to navigate user interfaceMaster valve/pump start circuit
- Non-Volatile (100 year) storage memory
- Program based scheduling allows 4 individual programs with 6 independent start times per program for 24 total start times
- Watering schedule options: By days of week, ODD calendar days, EVEN calendar days, or Cyclic (every 1 – 30 days)
- Advanced diagnostics and short detection with LED alert
- Contractor Default™ Program Save/Restore saved program(s)
- Rain Sensor bypass by Station
- Delay Watering up to 14 days (applies only to stations not set to ignore Rain Sensor)
- Manual Watering option by program or station
- Seasonal Adjust applied to all programs or individual program
- Adjustable delay between valves (default set to 0)
- Master Valve on/off by station
Specs
Flexible Installation
- Configurable to 22 stations with additional 3 or 6 station modules for different sized jobs or future irrigation needs. Comes with power plug and outdoor cabinet for indoor or outdoor installation.
Operating Specifications
- Station timing: 1 minute to 6 hours
- Seasonal Adjust; 5% to 200%
- Max operating temperature: 149°F (65°C)
Electrical Specifications
- Input required: 120 VAC ± 10%, 60Hz
- Output: 25.5 VAC 1A
- Master Valve/Pump Start Relay: Operating Voltage: 24VAC 50/60Hz, Max Coil Inrush: 11VA, Max Coil Holding: 5VA
- Idle/Off power draw 0.06 amps at 120VAC
- Power back-up not required. Nonvolatile memory permanently saves the current programming and a 10-year life lithium battery maintains the controllers time and date during power outages.
Downloads
- ESP-ME3 Brochure
- User Manual
- Quick Reference Guide
- Special Features Card
- Technical Specifications
- Compatible Flow Sensors
