Superior SPV200 2-Inch Plastic In-Line Irrigation Valve with Built-In Flow Control (NPT)

Description

Superior SPV200 – 2” FPT Plastic In-Line Valve with Forward Flow Design & Flow Control

Specifications

• Application: Commercial/municipal
• Size: 2” Female Pipe Thread
• Solenoid: Standard 24 VAC
• Flow: 50 to 200 GPM
• Pressure: 19 to 200 PSI
• Temperature: up to 150° F

Features

• Self Cleaning – Self-cleaning scrubbing rod and filter system provides optimal protection against particles entering the diaphragm chamber
• Low Seat – Low seat design decreases pressure loss and improves flow
• Diaphragm Reliability – Two-piece internal assembly protects diaphragm
• 600 lb. Test Nylon Reinforced EPDM Diaphragm
• Rotating Coil – Coil can be rotated 360° and removed without removing solenoid operator
• Flow Control – Maximize efficiency and prolong the life of a system by fine tuning flow and pressure for each zone.
• Internal and External Bleed
• Glass-filled nylon construction results in the highest pressure rating
• Low Flow Capability – Flow rates as low as 0.25 GPM
• All Superior valves are 100% water-tested prior to shipping, you can be sure they are working properly before ever coming into your hands.
• Interchangeable – Internal components interchangeable with Superior 950
• Warranty period: 5 years
