Toro T5 RapidSet Pop-Up Rotors – Case of 20, 5-inch, with Check Valve (T5PK-RS-CASE)

Description

The Toro® T5 RapidSet rotor can be set in seconds. Engineered to use the slip clutch to adjust the arc, the T5 RapidSet rotor requires NO TOOLS for arc adjustments. Along with a five-inch pop-up height, the T5 RapidSet rotors feature exclusive Airfoil Technology™ standard and low angle nozzles that deliver class leading distribution uniformity. Designed to save water, save time, and save money, the T5 RapidSet rotor is the only ¾” rotor needed to get the job done.

Includes:

• 20 x T5 Rapidset 5” Rotors with Check valve
• 20 Nozzle Trees (Includes 8 standard & 4 Low angle nozzles)
• No Tools needed for adjustment of arc from 40° to 360°! Tool is needed to lift the riser, change out nozzles, and adjust the radius. (Video Tutorial for Nozzle Installation)
• 1 Rotor Key included.
• If you need more than 1 key, it will need to be purchased separately. – Toro Rotor Key 102-7194

Operating Specifications

• Pop-up Height: 5”
• Radius: 25′ to 50′
• Flow Rate: 0.74 to 9.70 GPM
• Arc: 40° to 360° (reversing 360°), adjustable
• Check Valve: Yes
• Effluent: No
• Inlet Size: 3/4” FPT
• Recommended Operating Pressure: 45 PSI
• Operating pressure range: 25 to 65 PSI
• Nozzle trajectory: Std = 25 degrees, Low angle = 10 degrees

Overview

The new Toro T5 RapidSet Series Rotor has the features to satisfy all your basic irrigation needs while surprising you with a few extras. The T5 offers an extra inch of pop-up height compared to most competitive units. For those day-in and day-out installations, the T5 is the only rotor you’ll need.

Features

• Riser: Plastic
• Arc setting: 40 to 360 degrees, 360 degree non-reversing
• Arc adjustments from 40° to 360° can be made quickly with a few twists of the turret – no tools required. The patent-pending RapidSet slip clutch also protects against gear damage caused by intentional vandalism or inexperienced users.
• Pre-installed drain check valve keeps lines from draining when the system is shut off. This saves water, reduces liability, and increases system life. (up to 10′ of elevation)
• The T5 RapidSet rotor comes with a full set of 8 standard nozzles (25° trajectory) and 4 low angle (10° trajectory) nozzles.
• Airfoil Technology™ Nozzles unique geometry creates a zone of low pressure just below the main stream to gently guide water downward for unmatched uniformity without forcefully washing out newly-laid seeds.
• Easily replaces most competitive 4” pop-up rotors in the same footprint, but delivers an extra inch of nozzle clearance.

Dimensions

• Overall height:  7 1/2”
• Pop-up height: 5″
• Body diameter: 2 1/4”
• Inlet size: ¾”

Downloads

• T5 Brochure and Nozzle Specs
