UNVLS DS2336WB Large Brass Directional Spot Light – No Bulb Included

Description

Universal Lighting Systems – DS23336WB – Large Directional Spot Light (Weathered Brass Finish) – No Lamp Included (PAR36 Sold Separately)

The DS2336WB includes:

• DS2336WB Large cast brass Weathered Brass finish spotlight
• (GS1) ABS ground stake, 1/2” NPT thread, slotted for ease
  of installation
• No lamp included (Sold Separately)
• Includes two AC-102 silicone filled wire connectors
• 3’ – #18/2 direct bury landscape lighting wire with terminal spade connectors
• Fixture – lifetime warranty

Fixture Material/Features

• Solid brass fixture housing
• Cast Brass Knuckle Assembly
• Open faced, no lens fixture
• EPDM rubber bug plug, prevents moisture/bugs from entering fixture
• Key screw on knuckle for easy adjustments
• (WB) Weathered Brass: WB Brass finish will patina / tarnish depending on
  environmental conditions
• Fixture – lifetime warranty

Fixture Specifications

• Fixture Material: Solid brass and cast brass.
• Finish: 7 stage chemically aged, weathered bronze (WB) brass finish. Finish will patina / tarnish depending on environmental conditions.
• Socket Type: Dual fork terminal leads
• Lens Type: No lens
• Lamp Type: PAR 36 Lamp 75w max
• Mounting/Fasteners: Brass fasteners, brass knuckle screw. Included (GS1) ABS ground stake, ½” NPT tread slotted for easy wire installation.
• Wiring: EPDM rubber bug plug with prewired 3’ 18/2 awg direct-bury landscape lighting wire.
• Certification: CETL listed and approved
• Dimensions: 4.53” W x 3.15” D x 9.25” L (from thread to tip of cowling)

Electrical

• 12 volt fixture
• 3’ – #18/2 direct bury landscape lighting wire with terminal spade connectors
• Lamp required – PAR36 75 W Max (not included)
• Low voltage transformer required (not included)
• C ETL listed and approved
