Description
61135 – Black/White Waterproof Wire Connectors (25pc. Bag) – Min #22/Max #12 – Small Size
FEATURES & BENEFITS:
- UL Listed 600V for dry, wet or above/below grade applications when used in an enclosure
- For use in Direct Bury applications when operating at 30V or less
- Impact resistant
- #1 in the industry
- Waterproof and corrosion proof
- One-step® installation saves time and money
- No pre-twisting required
- Pre-filled with dielectric silicone sealant that never hardens
PRODUCT SPECIFICATIONS & MEASUREMENTS:
- Max. Voltage: 600V max. building wire (1000V max. signs or luminaires)
- Connector Size: 27/32” x 7/16”
- Wire Type: Copper/Copper
- Wire Range: Min #22/Max #12
- Temperature Rating: 105°C (221°F)
- Silicone Sealant: -45°F to 400°F
- UL Designation: SWP*
Documents
- King Innovation Product Guide
